High Accuracy, Temp. Monitor, Audible Alarm, Relay

(0)No Reviews yet
Provided: Each
-100.0°C ~ 100.0°C
Single Channel Digital Temperature Monitor-Alarm
Alarm Relay Contact Output SPDT
Audible Alarm Tone 80db
Battery Backup
Degree C° Display Standard °F is optional
Includes Calibration Certificate

Notable Features

The Model T°Sentry TS1 is a complete self-contained package. The high accuracy temperature probe (sensor) will monitor between -100°C to +100°C. ( Also Available in Degree °F ) The product has a standard resolution of 1.0 degree and an accuracy of +/- 1 degree Celsius, and is very flexible. For example, an operator can easily program set points and alarm activation timeouts - as well as varied delay periods for relay activation and audible alarm mute. Standard options include a built-in battery and charger for approximately 100 hours of operation in the event of a power failure. The unit also has several panels, mounting bracket options that enable wall, a cabinet top, or through-panel mounting. Applications typically cover the industrial markets and research including freezer, refrigerator, room temperature, computer room and walk-in environmental chamber monitoring. The operating program can also be customized (to modify the standard alarm sequence logic) for use in biological or blood storage applications. Standard features include: built-in Ni-MH battery with trickle charger, high resolution (0.1) in both display and alarm set, Relay (SPDT), and Calibration certificate (over full range of sensor). Optional Add Ons:
  • 4 to 20 mAoutput
  • Millivolt output 10 mVper degree
  • Ethernet interface
  • Digital output (specify RS232 or RS485)
Type of Sensor: RTD 100Ω
Temperature Sensing Range: -100.0°C ~ +100.0°C
Temperature Accuracy: +/- 1°F (+/- 0.5°C) typical
Temperature Resolution: 0.1°
Temperature Scale: °F or °C
Dimensions: 4" x 7" x 2"
Weight: 1.4
Power: 110-240V with 10 ft. cord with 2 pin US plug (included)
Battery Backup: Yes
Display: LCD
Network Connectivity: Optional Ethernet
  • Temperature Monitor °C with Power Cord
  • RTD Temperature Sensor with 10 Ft. cable with 2 pin US plug (longer lengths available please call )
  • Certificate of Calibration
  • Back-Up Battery
  • SPDT contact output
  • Instructions
  • Expert Technical Support
Optional Add Ons:
  • 4 to 20 mAoutput
  • Millivolt output 10 mVper degree
  • Ethernet interface
  • Digital output (specify RS232 or RS485)
  • View Instruction Manual
  • Includes 100Ω RTD Probes ( Standard )
  • Optional: P1000 1000Ω RTD, U Micro-amp current source, K-type thermocouple, T-type thermocouple
  • Standard Range -100 ~ 100 ºC, -148 ~ 212 ºF
  • Available Ranges
  • -200 to +50 ºC ( -328 ~ 106 ºF)
  • 0 ~ 400 ºC ( 32 to 752 ºF )
Call and Speak with a TIPTEMP Thermal Advisor
