Multi Change Paint MC470-9 Non-Reversible Multi-Change Indicating Thermal Paint
Multi-Change Paint MC470-9 supplied in 1 liter container.
Paint is applied at room temperature where the initial color is RED.
After 5 minutes at temperature the original color will change to the colors as listed below depending on the temperature.
1st color change from RED to BROWN at 470°C/878°F
2nd color change from BROWN to YELLOW at 600°C/1112°F
3rd color change from YELLOW to GREEN at 750°C/1382°F
4th color change from GREEN to ORANGE at 850°C/1562°F
5th color change from ORANGE to MOTTLED RED at 990°C/1814°F
6th color change from MOTTLED RED to GREEN GREY at 1060°C/1940°F
7th color change from GREEN GREY to GREY at 1120°C/2048°F
8th color change from GREY to MATT BLACK at 1200°C/2192°F
9th color change from MATT BLACK to GLAZE at 1210°C/2210°F
If the paint is not used for a number of months it may start to dry out. It can be re-vitalized by mixing in a PMA paint solvent.
- (1) Liter of Paint ( 5 minute response time )
- Typical Delivery N/A
- DISCONTINUED
Apply to a blast cleaned and degreased surface; no primer is necessary. Apply one coat, allowing to touch dry for 15-30 minutes. The best thermal mapping is achieved by an even coat of paint. The preferred application method is spraying. The paint may be thinned to spraying viscosity by the further addition of thinners. Removal of the paint can be achieved by using solvents or an abrasive disc.
Q: The technical data sheet lists the coverage area as "6", what unit of measure is this? meters?
A: 6 square metres per litre applied by brush is a good guide
Q: Is there a recommended depth/thickness for a coat of paint?
A: Normally, 60 - 80 microns is a good guide
Q: Can it be recoated over itself?
A: Yes, as long as the surface is pitted / rust-free and cleaned to allow the new coating to adhere fully and smoothly
Q: Is there a preferred "blast profile" that the surface should be to ensure the best coat?
A: Ideally, this should be taken back to clean blasted metal to gain the best results
