TC-9500 Bench-Top Temperature Controller

(0)No Reviews yet
Provided: Each
-248°F ~ 3000°F ( -100°C ~ 1650°C )
Features direct plug-in for heating devices.
Includes Audible and Visual out-of-range alarms

See Alternative BARCON003

Notable Features

Digi-Sense TC-9500 Thermocouple Temperature Benchtop Controller, 115V

Accepts eight thermocouple types with miniconnectors.

General features—Rear panel output receptacle for direct plug-in of heaters and other resistive devices. Field calibrations help to improve system accuracy by entering the offset value to correct for individual probe error. Simultaneously view both the measured and set point on the two-line alphanumeric display. Temperature scale selectable to read in °F, °C, K (Kelvin), or °R (Rankine). Front panel indicates output and alarm conditions. Multiple control modes from simple On/Off control to sophisticated autotuning PID control.

Safety features—Output power to load device is automatically shut down in the event of a broken sensor or control loop break. Overtemp feature protection shuts down the system if the user- settable over-temperature or timer is exceeded. Outlet power receptacle is fused separately from the controller for added safety. Audible and visual out-of-range alarms are also included.
The TC-9500 Multiparameter controller accept 8 thermocouple types with mini-connectors, thermistor probes with 1/4" phono plugs, RTD probes with standard 3-pin ANSI connectors, or Oakton®/Digi-Sense® RTD probe connector.

The Temp-9500 also features data logging, ramp-and-soak / ramp-rate profiling for more complicated processes, USB computer interface, alarm relay, and free software that features real-time graphing.
Type of Sensor: J, K, T, E, N, B, R, S, RTD, Thermistor
Temperature Sensing Range: -248°F ~ 3000°F ( -100°C ~ 1650°C )
Temperature Accuracy: Types J K T E and N: ±0.1% of reading ±0.7°F (0.4°C) above 248°F (100°C); ±0.1% of reading ±2°F (1°C) below 248°F (100°C) Types B R and S: ±0.1% of reading ±1.8°F (1.0°C) Thermistors and RTDs: ±0.1% of reading ±0.7°F (0.4°C)
Temperature Resolution: 0.1°; 1° above 999.9° and below 99.9°
Dimensions: 8" x 33/4" x 9" (20.3 x 9.5 x 22.9 cm)
Special Notes: Control type: on/off programmable PID autotune PID
Display: LCD
  • Benchtop Temperature Controller
  • 6 FT. Power Cord
  • Instructions
  • Expert Technical Support
  • Thermocouple sensors not included - See Related Items
