Multi Change Thermal Paint MC520-7
Paint is applied at room temperature where the initial color is PURPLE. After 5 minutes at temperature the original color will change to the colors as listed below depending on the temperature.
1st temp change - Purple to Pale Blue/Grey after 5 min @ 570°C/1,058°F
2nd temp change - Grey to Dark Blue/Grey 5 min @ 630°C/1,166°F
3rd temp change - Dark Blue/Grey to Blue 5 min @ 850°C/1,562°F
4th temp change - Blue to Midnight Blue 5 min @ 970°C/1,778°F
5th temp change - Midnight Blue to Matt Black 5 min @ 1,050°C/1,922°F
6th temp change - Matt Black to Matt Black Glaze 5 min @ 1,070°C/1,958°F
7th temp change - Matt Black Glaze to Dark Blue Glaze 5 min @ 1,270°C/2,316°F
If the paint is not used for a number of months it may start to dry out. It can be re-vitalized by mixing in a PMA paint solvent.
| Type of Sensor: | Thermal Paint |
| Temperature Sensing Range: | 1058°F~2316 °F (570°C~1270°C) |
| Dimensions: | 1 Liter |
| Weight: | 2.75 lbs. |
| Sold As: | 1 Liter |
| Data Points: | 7 Color Changes |
- (1) Liter of Paint ( 5 minute response time )
- Typical Delivery 3-4 Weeks ARO
Apply to a blast cleaned and de-greased surface, no primer is necessary. Apply one coat, allowing to touch dry to 15-30 minutes. Best thermal mapping is achieved by an even coat of paint. The preferred application method is spraying. The paint may be thinned to spraying viscosity by the further addition of thinners. Removal of the paint can be achieved by using solvents or an abrasive disc.
Q: The technical data sheet lists the coverage area as "6", what unit of measure is this? meters?
A: 6 square metres per litre applied by brush is a good guide
Q: Is there a recommended depth/thickness for a coat of paint?
A: Normally, 60 - 80 microns is a good guide
Q: Can it be recoated over itself?
A: Yes, as long as the surface is pitted / rust-free and cleaned to allow the new coating to adhere fully and smoothly
Q: Is there a preferred "blast profile" that the surface should be to ensure the best coat?
A: Ideally, this should be taken back to clean blasted metal to gain the best results
