⚙️🔥 CAL 3200 Series Temp Controller

✅ Ultra-compact 24mm × 48mm design
✅ Autotune PID for simplified setup
✅ Dual-output configuration (relay + SSR drive)
✅ Compatible with thermocouple and RTD/PT100 sensors
✅ Sealed IP65 / NEMA 4X front panel
✅ Clear LED display with selectable resolution
✅ Positive-feel front panel buttons
✅ Reliable and cost-effective industrial control

──────────────────────────

The CAL Controls 3200 Series was the world's first 1/32 DIN (24mm x 48mm) temperature controller launched in 1992. A key feature of the CAL Controls 3200 Series is the standard autotune functionality. Autotune ˜teaches' the controller the main characteristics of the process. For best results, run Autotune with the usual set-point temperature under normal load conditions. Autotune ˜learns' by cycling the output on and off. The results are measured and used to calculate optimum PID values, which are automatically entered in the controller memory. Standard inputs to the CAL Controls 3200 Series are 9 types of thermocouples as well as RTD-2/Pt100 2-wire resistance thermometers. Output devices include the solid state relay drive and miniature power relay.

The CAL Controls 3200 Series is still in full production today. For the very latest 1/32 DIN controller, see the CAL Controls 3300 which uses the same program menus but has the benefit of communications and latest aesthetic designs.
