20 Day Transit Temperature Recorder
20 Day Transit Temperature Monitor
Highly reliable battery powered time temperature strip chart recorders. These recorders generate a permanent paper print-out of the actual temperature conditions during transit. Once the goods reach their destination, the recorder is removed and the chart is easily extracted from the unit.
| Type of Sensor: | NIST Traceable Bi-metal Coil |
| Temperature Sensing Range: | -20°F ~ 100°F (-29°C ~ 38°C) |
| Temperature Accuracy: | +/- 2°F (+/- 1°C) typical |
| Temperature Scale: | °F and °C |
| Dimensions: | 6.5" x 3.5" x 2.67" (LxWxH) |
| Weight: | .65 |
| Calibration Available: | Certificate of Conformance ( $ Extra ) |
| Power: | AA Alkaline |
| Shelf Life: | 3 Years |
- 20 Day Transit Temperature Monitor
- Batteriesnot user replaceable; unit is single use only
- Instructions
- Expert Technical Support
The unit is easily activated by simply removing a start tab.
The unit is then sealed up and placed at the desired monitoring location. At destination or at the end of the recording episode, the chart is removed from the recorder and the temperature history is reviewed. Temperature vs. time is clearly graphed on a narrow strip of pressure-sensitive paper.
The clear view port confirms running after the start strip is pulled. Carbon copy evidence of the trip is provided by the integral form on the recorder
