Inor IPAQ C202 Transmitter
Programmable 2-wire Transmitter dedicated for Pt100 sensors
IPAQ C202 is a digital, easy-to-use temperature transmitter developed specifically for measurements with Pt100 sensors.
Its robust design and high quality gives excellent performance and accuracy also under harsh conditions. With the new runtime counter function you can easily supervise the elapsed operational time between calibrations.
The IPAQ C202 is also available with ATEX and IECEx certificates making it suitable for a wide range of applications.
IPAQ C202 is a digital, easy-to-use temperature transmitter developed specifically for measurements with Pt100 sensors.
Its robust design and high quality gives excellent performance and accuracy also under harsh conditions. With the new runtime counter function you can easily supervise the elapsed operational time between calibrations.
The IPAQ C202 is also available with ATEX and IECEx certificates making it suitable for a wide range of applications.
| Type of Sensor: | RTD |
| Temperature Sensing Range: | -328~1562°F (-200~850°C) |
| Temperature Scale: | °F or °C |
| Dimensions: | 18.5 mm / 0.72 inch high |
| Weight: | 0.05 |
| Calibration Available: | Yes (included) |
| Special Notes: | Configuration without external power |
| Requires Software: | Easy-to-use Windows configuration software |
- The transmitter can easily be configured from a PC by using the ConSoft software and a ICON Configurations kit.
- Thanks to the user-friendly interface, you can within seconds set and re-set parameters like temperature measurement range, TAG identity and failure indication.
- Robust terminals with test connections
- Input: Pt100 in 3-wire connection
- PC configurable measuring ranges without need for calibration
- Floating zero with minimum span 20°C
- Temperature linear output
- Runtime counter
- Excellent EMC immunity
- Configuration without external power
- USB communication
- Withstands vibrations up to 10 g
