Voltage Data Logger
The MATREC302 is one of TIPTemp's newest data loggers. It is part of a new series of low cost, state-of-the-art data logging devices. TIPTemp has taken the lead in offering the most advanced, low cost, battery powered data loggers in the world today.
The MATREC302 offers a 10 year battery life, 4Hz reading rate, a multiple start/stop function, ultra-high speed download capability, 1 million reading storage capacity, optional memory wrap, battery life indicator, optional password protection, programmable high-low alarms and more. Our research has shown that the MATREC302 is second to no other data logger when it comes to price and performance.
Using the free software, starting, stopping and downloading from the device is simple and easy. Graphical, tabular and summary data is provided for analysis and data can in multiple units, using the Engineering Units function. The data can also be automatically exported to Excel® for further calculations.
We offer free firmware upgrades for the life of the product so that data loggers already deployed in the field can grow with new technological developments. Units do not need to be returned to the factory for upgrades. The user can do this automatically from any PC.
The MATREC302 offers a 10 year battery life, 4Hz reading rate, a multiple start/stop function, ultra-high speed download capability, 1 million reading storage capacity, optional memory wrap, battery life indicator, optional password protection, programmable high-low alarms and more. Our research has shown that the MATREC302 is second to no other data logger when it comes to price and performance.
Using the free software, starting, stopping and downloading from the device is simple and easy. Graphical, tabular and summary data is provided for analysis and data can in multiple units, using the Engineering Units function. The data can also be automatically exported to Excel® for further calculations.
We offer free firmware upgrades for the life of the product so that data loggers already deployed in the field can grow with new technological developments. Units do not need to be returned to the factory for upgrades. The user can do this automatically from any PC.
- Part number MATREC302
- Voltage Range: 0 to 2.5VDC 0 to 15VDC or 0 to 30VDC
- Voltage Resolution:
0 to 2.5VDC: 0.1mVDC
0 to 15VDC: 0.5mVDC
0 to 30VDC: 1.0mVDC - Voltage Calibrated Accuracy: +/- 0.05%
- Memory: 1000000 readings (330000 in enhanced start/stop mode)
- Sample Rate: 4 readings every second to 1 reading every 24 hours
- Baud Rate: 115200
- LED Indicators: Red & Green
- Typical Battery Life: 10 years typical at a 15 minute reading rate
- Material: ABS Plastic
- Dimensions: 1.4" x 2.5" x 0.6" (36mm x 64mm x 16mm)
- Operating Environment: -40°C~+80°C 0~95%RH non-condensing
- Voltage Data Logger
- Battery
- Expert Technical Support
